| CPU |
Dual Intel® Xeon® Silver processor |
| Display Modes |
Unlimited
Customizable
Sequence |
| Display Speed |
Up to 30fps per channel |
| Local Video Outputs |
1x mini Display Port
Mini Display Port to true HD adapter (included) |
| Memory |
32GB |
| Video Card |
Nvidia Quadro |
| Video Compression |
H.264
H.265 |
| Video Operating System |
Linux® Ubuntu Desktop 20.04.3 LTS for IoT OS (DW-BJRR2P160TLX, DW-BJRR2P80TLX)
Windows Server® 2022 Standard (DW-BJRR2P160TS, DW-BJRR2P80TS, DW-BJRR2P100TS, DW-BJRR2P120TS, DW-BJRR2P140TS, DW-BJRR2P180TS, DW-BJRR2P200TS, DW-BJRR2P220TS, DW-BJRR2P240TS, DW-BJRR2P80TS6 , DW-BJRR2P100TS6, DW-BJRR2P140TS6, DW-BJRR2P160TS6, DW-BJRR2P180TS6, DW-BJRR2P200TS6, DW-BJRR2P220TS6, DW-BJRR2P240TS6)
Linux® Ubuntu Desktop 20.04.5 LTS OS (DW-BJRR2P100TLX, DW-BJRR2P120TLX, DW-BJRR2P140TLX, DW-BJRR2P180TLX, DW-BJRR2P200TLX, DW-BJRR2P220TLX, DW-BJRR2P240TLX, DW-BJRR2P80TLX6, DW-BJRR2P100TLX6, DW-BJRR2P120TLX6, DW-BJRR2P140TLX6, DW-BJRR2P160TLX6, DW-BJRR2P180TLX6, DW-BJRR2P200TLX6, DW-BJRR2P220TLX6, DW-BJRR2P240TLX6)
Windows Server® 2019 Standard
Windows® 10 IoT Enterprise LTSC (DW-BJRR2P160T, DW-BJRR2P80T, DW-BJRR2P100T, DW-BJRR2P120T, DW-BJRR2P140T, DW-BJRR2P180T, DW-BJRR2P200T, DW-BJRR2P220T, DW-BJRR2P240T, DW-BJRR2P80T6, DW-BJRR2P100T6, DW-BJRR2P120T6, DW-BJRR2P140T6, DW-BJRR2P160T6, DW-BJRR2P180T6, DW-BJRR2P200T6, DW-BJRR2P220T6, DW-BJRR2P240T6) |
| OS on SSD |
2 x 480GB NVMe SSD (RAID1) |
| Max throughput (Mbps) |
600Mbps |
| Raw internal storage options |
         |
| RAID Options |
OS RAID1
RAID5 (DW-BJRR2P160T, DW-BJRR2P160TLX, DW-BJRR2P160TS, DW-BJRR2P80T, DW-BJRR2P80TLX, DW-BJRR2P80TS, DW-BJRR2P100TS, DW-BJRR2P120TS, DW-BJRR2P140TS, DW-BJRR2P180TS, DW-BJRR2P200TS, DW-BJRR2P220TS, DW-BJRR2P240TS, DW-BJRR2P100T, DW-BJRR2P120T, DW-BJRR2P140T, DW-BJRR2P180T, DW-BJRR2P200T, DW-BJRR2P220T, DW-BJRR2P240T, DW-BJRR2P100TLX, DW-BJRR2P120TLX, DW-BJRR2P140TLX, DW-BJRR2P180TLX, DW-BJRR2P200TLX, DW-BJRR2P220TLX, DW-BJRR2P240TLX)
RAID6 (DW-BJRR2P80TS6 , DW-BJRR2P100TS6, DW-BJRR2P140TS6, DW-BJRR2P160TS6, DW-BJRR2P180TS6, DW-BJRR2P200TS6, DW-BJRR2P220TS6, DW-BJRR2P240TS6, DW-BJRR2P80T6, DW-BJRR2P100T6, DW-BJRR2P120T6, DW-BJRR2P140T6, DW-BJRR2P160T6, DW-BJRR2P180T6, DW-BJRR2P200T6, DW-BJRR2P220T6, DW-BJRR2P240T6, DW-BJRR2P80TLX6, DW-BJRR2P100TLX6, DW-BJRR2P120TLX6, DW-BJRR2P140TLX6, DW-BJRR2P160TLX6, DW-BJRR2P180TLX6, DW-BJRR2P200TLX6, DW-BJRR2P220TLX6, DW-BJRR2P240TLX6) |
| Max HDD Bay |
12x SATA HDD |
| Maximum Storage |
80TB (40TB, RAID6) (DW-BJRR2P80TS6 , DW-BJRR2P80T6, DW-BJRR2P80TLX6)
80TB (DW-BJRR2P80T, DW-BJRR2P80TLX, DW-BJRR2P80TS)
100TB (60TB, RAID6) (DW-BJRR2P100TS6, DW-BJRR2P100T6, DW-BJRR2P100TLX6)
100TB (80TB, RAID5) (DW-BJRR2P100TS, DW-BJRR2P100T, DW-BJRR2P100TLX)
120TB (100TB, RAID5) (DW-BJRR2P120TS, DW-BJRR2P120T, DW-BJRR2P120TLX)
120TB (80TB, RAID6) (DW-BJRR2P120TS6, DW-BJRR2P120T6, DW-BJRR2P120TLX6)
140TB (120TB, RAID5) (DW-BJRR2P140TS, DW-BJRR2P140T, DW-BJRR2P140TLX)
140TB (100TB, RAID6) (DW-BJRR2P140TS6, DW-BJRR2P140T6, DW-BJRR2P140TLX6)
160TB RAID 5 (140TB usable storge) (DW-BJRR2P160T, DW-BJRR2P160TLX, DW-BJRR2P160TS)
160TB (120TB, RAID6) (DW-BJRR2P160TS6, DW-BJRR2P160T6, DW-BJRR2P160TLX6)
180TB (140TB, RAID6) (DW-BJRR2P180TS6, DW-BJRR2P180T6, DW-BJRR2P180TLX6)
180TB (160TB, RAID5) (DW-BJRR2P180TS, DW-BJRR2P180T, DW-BJRR2P180TLX)
200TB (160TB, RAID6) (DW-BJRR2P200TS6, DW-BJRR2P200T6, DW-BJRR2P200TLX6)
200TB (180TB, RAID5) (DW-BJRR2P200TS, DW-BJRR2P200T, DW-BJRR2P200TLX)
220TB (180TB, RAID6) (DW-BJRR2P220TS6, DW-BJRR2P220T6, DW-BJRR2P220TLX6)
220TB (200TB, RAID5) (DW-BJRR2P220TS, DW-BJRR2P220T, DW-BJRR2P220TLX)
240TB (200TB, RAID6) (DW-BJRR2P240TS6, DW-BJRR2P240T6, DW-BJRR2P240TLX6)
240TB
240TB (220TB, RAID5) (DW-BJRR2P240TS, DW-BJRR2P240T, DW-BJRR2P240TLX) |
| Accessories |
Keyboard
Mouse |
| Included IP licenses |
8 (2xDW-SPECTRUMLSC004) |
| Operating Temperature and Humidity |
20 ~ 90% RH
41 ~ 104 °F (5~40 °C) |
| Rail kit |
Included |
| Recorder Dimensions (H X W X D) |
3.41” x 18.97” x 28.4” (86.8 x 482 x 721.62mm) |
| Recording Licenses (Optional. Sold Separately) |
Custom-ordered licenses are available by request.
DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder Licenses
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder Licenses
DW-SPECTRUMLSC001 - Single DW Spectrum® Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum® Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum® Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum® Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum® Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum® Recording Licenses
DW-SPIOLSC001 - Single DW Spectrum® I/O Module License
DW-SPVWALL1X2 - Single DW Spectrum® Video Wall License
Lifetime upgrades are included with no annual renewal fees. |
| USB interface |
Yes |
| Warranty |
5 Year Warranty
keep your hard drive
Next business day on-site hardware service (after remote diagnosis) |
| Weight (barebone, HDD not included) |
66 lbs (29.93 kg) |
| Certification |
      |
| Form Factor |
Rack mount |
